ÖLFLEX® TRUCK 470 P 2X1,0 WH/BK

Name: ÖLFLEX® TRUCK 470 P 2X1,0 WH/BK
Brand: LAPP
SKU: 7027080
Price: 67366 VND
Availability: OutOfStock

Vehicle cable; 2X1; white / black; 60 V; PUR; Core identification: Colours; ADR approval; Fixed installation

LAPPSKU: 7027080Article No.#: 7027080

Vehicle cable; 2X1; white / black; 60 V; PUR; Core identification: Colours; ADR approval; Fixed installation

67.366₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Benefits

Special ADR approval, ADR approval enables use in vehicles transporting hazardous goods

Applications

For commercial verhicles, Wiring of electrical equipments in all trailers and semi-trailers

Technical Attributes

General Information

Electrical Characteristics

Nominal voltage	60 V DC according to IEC
Max. conductor resistance at 20°C	19.5 Ω/km
Test voltage	5 kV

Product Design

Core identification	Colours
Core colours	white / black
Shape of cable	Round
base material inner sheath shortname	PVC
Outer sheath colour	black
Conductor design	fine-wire
Nominal outer diameter	6 mm
Conductor material	Bare copper
Number of cores	2
Nominal conductor cross-section (metric)	1 mm²
Core insulation basic material	Polyvinylchloride
FL vehicle cables	FLRYY11Y
Conductor count/size	2X1
Basic material of outer sheath	Polyurethane
Basic material of inner sheath	Polyvinylchloride
Including protective earth
Core insulation basic material, short form	PVC
With armouring
Basic material of outer sheath, short form	PUR

Product Characteristics

Flame-retardant
Application area	Fixed installation
Temperature class according to ISO 6722	A
PWIS-free according to	VDMA 24364-B2-L
Oil-resistant
Chemical resistant
UV-resistant
Minimum bending radius, stationary	12 x outer diameter
Temperature, fixed installation	-40 °C to 85 °C max. conductor temperature:
Flame retardance according to	ISO 6722-1 5.22
Minimum bending radius in mm, fixed installation	72.0 mm
PWIS-free
Halogenfree

Certifications and Standards

Flame retardance tested according to UN/ECE-R118
CE marked
ADR approval
Product standard ISO	ISO 6722
VDE certified
EAC certification number	ЕАЭС N RU Д-DE.АЮ64.В.00130/20
EAC-certified

Documentation

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Product Family List

Article number	Conductor count/size	Core colours	Nominal outer diameter	Weight
7027020	2X1,5	white / black	6.6	66 kg/km
7027021	2X1,5	white / brown	6.6	66 kg/km
7027022	3X1	white / brown / blue	6.3	64 kg/km
7027024	18X1,5		13.7	407 kg/km
7027025		white / brown / green / red / grey / violet	9	129 kg/km
7027030	10X1,5+3X2,5+2X1,5	white / black / yellow / red / green / brown / blue / light brown / null	14.4	395 kg/km
7027031	3X2,5+10X1,5	white / orange / white/red / yellow / green / blue / black / brown / red / pink / grey / white/black / white/blue	14.4	367 kg/km
7027032	25X1,5		16.1	560 kg/km
7027046	2X0,75+2X1,5	yellow / green / white / brown	7.2	85 kg/km
7027080	2X1	white / black	6	53 kg/km
7027081	2X1	white / brown	6	53 kg/km
7027082	3X1	black / brown / blue	6.3	64 kg/km
7027083	4X1	white / black / red / brown	6.8	81 kg/km
7027084	5X1	white / brown / green / red / grey	7.5	94 kg/km
7027085	5X1+1X2,5	white / green / brown / red / blue / violet	9	129 kg/km
7027088	7X1,5	white / black / yellow / red / green / brown / blue	8.9	166 kg/km
7027089	1X2,5+8X1,5		11.7	233 kg/km
7027090	10X1,5+3X2,5+1X(2X1,5)		14.4	395 kg/km
7027091	10X1,5+3X2,5		14.4	367 kg/km
7027092	2X6+3X1,5		12.1	267 kg/km
7027093	2X6+3X1,5+1X(2X1,5)		12.1	294 kg/km
7027094	2X4+3X1,5+1X(2X1,5)		11.9	257 kg/km
7027130	7X0,75	white / black / yellow / red / green / brown / blue	7.3	101 kg/km
