EPIC® H-B 6 TBF 13.5 ZW

Name: EPIC® H-B 6 TBF 13.5 ZW
Brand: LAPP
SKU: 10014000
Price: 1120947 VND
Availability: OutOfStock

Cable coupler hood; Design size: 6B; Connector design: Standard; Single lever; Number of cable entries: 1; Aluminium, Powder-coated; IP protection rating mounted: IP 65

Primary Image

LAPPSKU: 10014000Article No.#: 10014000

EPIC® H-B 6 TBF 13.5 ZW

Cable coupler hood; Design size: 6B; Connector design: Standard; Single lever; Number of cable entries: 1; Aluminium, Powder-coated; IP protection rating mounted: IP 65

EPIC® H-B 6 TBF 13.5 ZW

1.120.947₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Certificate

Benefits

Modular connectors offer a wide range of possible combinations and can be assembled flexibly - even to create hybrid connectors for different media

The module frame offers 2 slots for equipping with module inserts

With PE screw contact on the side to attach a protective earth by means of a ring eyelet. Connecting a protective earth via the module frame integrates the frame and the housing into the protective measures

Made of robust plastic (flammability class V-0 according to the UL94 testing procedure for the flammability of plastics)

UL certification according to technical data enables the product to be used on the North American market.

Applications

For the production of a modular connector

For use with the rectangular connector module inserts from the EPIC® MC series

For use with many EPIC® rectangular connector housings.

Technical Attributes

General Information

Product type	MC frame modular system
Brand	EPIC®
Installation type	clip on
Design size	6B
Contacts included
Delivery Unit	10.000

Electrical Characteristics

Protective conductor integrated into insert

Product Design

Contact insert type	Plug
Protective conductor contact type	Screw connection
Number of PE contacts	1
Number of data contacts	0
EMC screening
With wire protection
Colour	black
Number of contacts	1
First make, last break PE contact
Screen contact
Material	Polyamide
Number of signal contacts	0
With protective conductor
Material shortname	PA
Number of slots	2
Number of power contacts	0

Product Characteristics

Flame-retardant
Min. number of insertion cycles	500
Pollution degree	3
Operating temperature min.	-40
Operating temperature max.	100
Halogenfree
Short-term temperature peaks	125

Certifications and Standards

Tested for fire protection for railway vehicles
TÜV certified
Product standard according to IEC	IEC 61984
UR certification	according to UL 1977 (e-file number: E75770)
UR recognized
cUR recognized
CSA certified
cUR certification	according to CSA C22.2 No. 182.3 (e-file number: E75770)
VDE registration number	A870
CE marked
VDE certified
UL category control number	ECBT2

Documentation

Further Links

EPLAN Data in EPLAN Data Portal

Notes

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
