ÖLFLEX® POWER MULTI 25G16AWG

Name: ÖLFLEX® POWER MULTI 25G16AWG
Brand: LAPP
SKU: 611625
Price: 3723714 VND
Availability: OutOfStock

Power and control cable; 25G1.5; U₀/U: 300/500 V; Core identification: Colours and Numbers; UL listed; Flexible

LAPPSKU: 611625Article No.#: 611625

Power and control cable; 25G1.5; U₀/U: 300/500 V; Core identification: Colours and Numbers; UL listed; Flexible

3.723.714₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Certificate

Benefits

Cable especially developed for use in the USA

UL-listed according to type TC (Tray Cable) or TC ER (Tray Cable for Exposed Run) and STOOW (extra-hard usage flexible cord (600 V))

Outer sheath made of special thermoplastic polymer for heavy industrial stress and improved longevity

Core insulation made of special PVC compound

Particularly oil-resistant and flame-retardant

High thermal resistance and good cold flexibility.

Applications

Suitable as flexible direct line or extension cable

For unprotected installation and occasional use in the end consumer circuit

For open installation in cable trays without a protective conduit

For occasional flexing in potentially explosive atmospheres in the USA

Cable design and outer sheath make it suitable for use in harsh, oily industrial environments

Suitable for outdoor use, subject to the temperature range

For universal use in Europe for the wiring of cross-plant control circuits and control circuits inside machines

In Europe for fixed installation and occasional flexing.

Technical Attributes

General Information

Electrical Characteristics

Nominal voltage	U₀/U: 300/500 V AC rms according to IEC
Max. conductor resistance at 20°C	13.3 Ω/km
Test voltage	2 kV
Current rating according to	NEC / NFPA 70, NFPA 79, IEC 60364-5-52
Rated voltage	600 V AC rms according to UL TC, 600 V AC rms according to UL STOOW, 600 V AC rms according to c(UL) CIC/TC, 600 V AC rms according to cUL STOOW, 600 V AC rms according to CSA AWM

Product Design

Nominal core diameter	3.18
Conductor design	IEC 60228 class 5: fine-wire
Nominal outer diameter	24.5 mm
Conductor material	Bare copper
Min. outer diameter	23.65
Nominal conductor cross-section (metric)	1.5 mm²
Cable dimension	25G1.5
Shielded
Core identification	Colours and numbers
Shape of cable	Round
Outer sheath colour	black
Leading conductor cross-section	mm²
Number of cores	25
Nominal conductor cross-section (AWG)	16 AWG
Core insulation basic material	Polyvinylchloride
Basic material of outer sheath	Thermoplastic
Including protective earth
Core insulation basic material, short form	PVC
Max. outer diameter	25.43

Product Characteristics

Flame-retardant
Storage temperature min.	-40
Ozone resistant
UV-resistant
Minimum bending radius in mm, fixed installation	101.7 mm
Application area	Flexible, Fixed installation
max. conductor temperature, occasionally moved	-25 °C to 105 °C max. conductor temperature:, -25 °C to 90 °C max. conductor temperature: according to UL STOOW, -25 °C to 90 °C max. conductor temperature: according to CSA AWM
Oil-resistant
Max. storage temperature	40
Mechanically resistant
Minimum bending radius in mm, occasionally flexing	101.7 mm
weather resistant
Minimum bending radius, stationary	4 x outer diameter
Water resistant
Minimum bending radius, occasionally flexing	4 x outer diameter
Suitable for use in accordance with NEC chapter 5	Class I Division 1
Temperature, fixed installation	-40 °C to 105 °C max. conductor temperature:, -25 °C to 90 °C max. conductor temperature: according to UL/CSA TC, -40 °C to 90 °C max. conductor temperature: according to CSA AWM
Flame retardance according to	UL Vertical-Tray Flame Test, CSA FT4, IEC 60332-3-24
Oil resistance according to	UL OILRES I, UL OILRES II, CSA C22.2 No. 210-15
UV-resistant according to	UL sunlight resistant, EN 50525-1 (cables with a black sheath are suitable for permanent outdoor use)
For torsional load
Halogenfree

Certifications and Standards

cUR recognized
CSA certified
HAR-certified
UL certification	UL TC-ER according to UL 1277 (e-file number: E171371), UL STOOW according to UL 62 (e-file number: E146118)
Ecolab certified
cUL listed
UL listed
CE marked
cUL certification	cUL CIC/TC 600V according to CSA C22.2 No. 239 / CSA C22.2 No. 230 (e-file number: E171371), cUL STOOW according to CSA C22.2 No. 49 (e-file number: E146118)
UL recognized
VDE certified
CSA certification	AWM I A according to CSA C22.2 No. 210, AWM I B according to CSA C22.2 No. 210, AWM II A according to CSA C22.2 No. 210, AWM II B according to CSA C22.2 No. 210

Documentation

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Product Family List

Article number	Nominal conductor cross-section (AWG)	Number of cores	Conductor cross-section (mm2)	Including protective conductor	Nominal outer diameter	Weight	Copper index (lb)
610803	8 AWG	3	10	Yes	21.3	641 kg/km	1940.000
610804	8 AWG	4	10	Yes	24.0	844 kg/km	2580.000
611003	10 AWG	3	6	Yes	17.2	342 kg/km	1161.000
611004	10 AWG	4	6	Yes	18.6	402 kg/km	1550.000
611203	12 AWG	3	4	Yes	16.0	188 kg/km	774.000
611205	12 AWG	5	4	Yes	18.8	286 kg/km	1290.000
611403	14 AWG	3	2.5	Yes	13.8	137 kg/km	484.000
611404	14 AWG	4	2.5	Yes	14.8	167 kg/km	650.000
611405	14 AWG	5	2.5	Yes	16.8	198 kg/km	810.000
611603	16 AWG	3	1.5	Yes	10.1	110 kg/km	290.000
611604	16 AWG	4	1.5	Yes	10.9	128 kg/km	390.000
611605	16 AWG	5	1.5	Yes	12.9	153 kg/km	484.000
611612	16 AWG	12	1.5	Yes	18.3	330 kg/km	1161.000
611618	16 AWG	18	1.5	Yes	20.9	440 kg/km	1742.000
611625	16 AWG	25	1.5	Yes	24.5	598 kg/km	2420.000
611803	18 AWG	3	1	Yes	9.4	92 kg/km	200.000
611804	18 AWG	4	1	Yes	10.1	106 kg/km	260.000
611805	18 AWG	5	1	Yes	12.0	122 kg/km	330.000
611812	18 AWG	12	1	Yes	16.1	260 kg/km	774.079
