SILVYN® US-M 25X1.5 EDU

Name: SILVYN® US-M 25X1.5 EDU
Brand: LAPP
SKU: 55502636
Price: 1591014 VND
Availability: OutOfStock

Conduit gland; M 25; Nominal size: 27; Halogenfree; UV-resistant; IP 40;

LAPPSKU: 55502636Article No.#: 55502636

Conduit gland; M 25; Nominal size: 27; Halogenfree; UV-resistant; IP 40;

1.591.014₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Certificate

Benefits

Fast and easy assembly

Applications

Mechanical engineering, Plant engineering

Technical Attributes

General Information

Including lock nut
Including o-ring
Brand	SILVYN®
Product type	Conduit gland
Scope of delivery	including O-ring
Packaging type	Bag
Installation type	in threaded borehole, with lock nut
Delivery Unit	25.000
Weight	0.072 kg

Electrical Characteristics

Product Design

Nominal size	27
Total length	41
Divisible fitting
Thread type	Metric
EMC screening
Thread size	M 25
Screw-in sleeve material	Brass
Thread length	11
Gland body material	Brass
Conduit gland design	Straight
Cable gland body material, short form	CuZn
Bending protection
Clear width	20.5
O-ring material, short form	NBR
Bending protection fixed installation
O-ring material	Acrylonitrile butadiene rubber
Pitch of thread	1,5
Surface protection	Nickel-plated
Flexibly installed bending protection
Rotatable thread
Spanner size 1	34
Thread standard	DIN EN 60423
Spanner size 2	36

Product Characteristics

Flame-retardant
IP protection rating	IP 40
UV-resistant
Oil-resistant
Suitable for EX-applications
Impact-resistant
Halogenfree

Certifications and Standards

Documentation

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
