SILVYN® MPC PG42 GY

Name: SILVYN® MPC PG42 GY
Brand: LAPP
SKU: 55502456
Price: 414018 VND
Availability: OutOfStock

Conduit gland; PG 42; Suitable for protective cable conduit size: 50; Polyamide; Halogenfree; IP 67, IP 65;

LAPPSKU: 55502456Article No.#: 55502456

Conduit gland; PG 42; Suitable for protective cable conduit size: 50; Polyamide; Halogenfree; IP 67, IP 65;

SILVYN® MPC PG42 GY

414.018₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Certificate

Benefits

All-purpose, Fast and easy assembly

Applications

In combination with protective conduit:, SILVYN® EL/ELU/ELO/ELT/ELR (helically formed and smooth conduits)

Technical Attributes

General Information

Electrical Characteristics

Product Design

Lockable (two-part)
Divisible fitting
Suitable protective conduit	SILVYN® EL smooth, SILVYN® ELU, SILVYN® ELU smooth, SILVYN® ELÖ, SILVYN® ELÖ smooth, SILVYN® ELT, SILVYN® ELT smooth, SILVYN® ELR
Material body	Polyamide
Thread type	PG
EMC screening
Material body shortname	PA
Thread size	PG 42
Colour	grey
Thread length	12
Gland body material	Polyamide
Conduit gland design	Straight
Suitable for protective cable conduit size	50
Cable gland body material, short form	PA
Hexagon corner dimensions	67.5
Spanner size	60
Bending protection
Clear width	39
Max. clamping range	60
Bending protection fixed installation
RAL colour	RAL 7001
Pitch of thread	1,588
Flexibly installed bending protection
Rotatable thread
Spanner size 1	60
Min. clamping range	39

Product Characteristics

Flame-retardant
IP protection rating	IP 67, IP 65
Acid-resistant
Chemical resistant
UV-resistant
Oil-resistant
Strain relief
Suitable for EX-applications
Impact-resistant
Halogenfree

Certifications and Standards

EHEDG certified
DNV-certified
cUR recognized
CSA certified
FDA certified
GGVS certified
Tested for fire protection for railway vehicles
Product standard according to IEC	IEC 61386-1, IEC 61386-23
Ecolab certified
cUL listed
UL listed
CE marked
UL recognized
NSF certified
VDE certified

Documentation

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Product Family List

Article number	Thread size	Colour	Suitable for protective cable conduit size	Delivery Unit
55502451	PG 16	grey	20	10.000
55502452	PG 21	grey	25	10.000
55502453	PG 29	grey	30	10.000
55502454	PG 29	grey	32	10.000
55502455	PG 36	grey	40	2.000
55502456	PG 42	grey	50	2.000
55502457	PG 48	grey	63	1.000
55502470	PG 9	black	12	10.000
55502471	PG 11	black	16	10.000
55502472	PG 13,5	black	16	10.000
55502473	PG 16	black	20	10.000
55502474	PG 21	black	25	10.000
55502476	PG 29	black	30	10.000
55502477	PG 36	black	40	2.000
55502478	PG 42	black	50	2.000
55502479	PG 48	black	63	1.000
55502494	PG 13,5	black	20	10.000
55502495	PG 29	black	32	10.000
55502496	PG 9	grey	12	10.000
55502497	PG 11	grey	16	10.000
55502498	PG 13,5	grey	16	10.000
55502499	PG 13,5	grey	20	10.000
