EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8

Name: EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8
Brand: LAPP
SKU: 44423325
Price: 21593 VND
Availability: OutOfStock

Contact; Socket; Crimp termination; For cross-section (min./max.): 0.09mm² - 0.25mm²; Brass Gold-plated

Primary Image

LAPPSKU: 44423325Article No.#: 44423325

EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8

Contact; Socket; Crimp termination; For cross-section (min./max.): 0.09mm² - 0.25mm²; Brass Gold-plated

EPIC® MH BCEG 0.09 - 0.25sqmm D=0.8

21.593₫

Thanh toán & Bảo mật

Thông tin thanh toán của bạn được xử lý an toàn. Chúng tôi không lưu trữ chi tiết thẻ tín dụng cũng như không có quyền truy cập vào thông tin thẻ tín dụng của bạn.

Lợi ích

Modular connector system, plugable with the market standard, Gold-plated contacts for low transfer resistance

Ứng dụng

Mechanical and plant engineering, Robotics industry, Renewable energy, Railway applications / vehicle construction

Thuộc tính kỹ thuật

Thông tin chung

Brand	EPIC®
Installation type	crimp
Product type	Contact
Contact delivery type	Bag
Delivery Unit	100.000
Weight	0.014 kg

Đặc tính điện

Thiết kế sản phẩm

Max. connectable conductor cross-section AWG	24 AWG
Connectable conductor cross section min. (AWG)	28 AWG
Max. connectable conductor cross-section (mm2)	0.25
Min. connectable conductor cross-section (mm2)	0.09
Conductor connection type	Crimp termination
Contact variant	Socket
Contact diameter	0.8
Contact material	Brass
Contact material, short form	CuZn
Material contact surface	Gold-plated
Contact coating material, short form	Au
Contact manufacturing method	Stamped
Stripping length of single core	4.0

Đặc điểm sản phẩm

Chứng nhận và Tiêu chuẩn

CE marked
CSA certified
cUR recognized
Tested for fire protection for railway vehicles
TÜV certified
UR recognized
VDE certified

Tài liệu

Further Links

EPLAN Data in EPLAN Data Portal

Notes

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.
