UNITRONIC® LAN 500 S/FTP Cat.6A Y

Name: UNITRONIC® LAN 500 S/FTP Cat.6A Y
Brand: LAPP
SKU: 2170143
Price: 55725 VND
Availability: OutOfStock

Ethernet cable; Fixed installation; ETHERNET/IP, Ethernet; Cat.6A; S/FTP; PVC; ivory

LAPPSKU: 2170143Article No.#: 2170143

Ethernet cable; Fixed installation; ETHERNET/IP, Ethernet; Cat.6A; S/FTP; PVC; ivory

55.725₫

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Product characteristics

Certificate

Benefits

Fast information exchange through Ethernet technology. , Cat. 6A performance up to 10 Gbit/s

For transmission of analogue and digital signals in the frequency range up to 500 MHz

Available with robust PVC or halogen free LSZH outer sheath

Classified fire behaviour according to EU Directive 305/2011 (BauPVO/CPR) with article number selection on the LAPP website.

Applications

For fixed installation and structured building cabling according to EN 50173 and ISO/IEC 11801

For horizontal floor cabling with a max. cable length of 100 m (90 m for installation and 10 m at the workstation)

Suitable for all LAN networks and Ethernet applications up to 10GBASE-T.

Technical Attributes

General Information

Brand	UNITRONIC®
Product type	Ethernet cable
valid fieldbus or Ethernet system	ETHERNET/IP, Ethernet
Copper index	27.000 kg/km
Copper index (lb)	181.400 lb
Weight	58 kg/km

Electrical Characteristics

Maximum operating voltage (not for power transmission)	100
Nominal surge impedance	100
Supports Power over Ethernet	IEEE 802.3af (PoE), IEEE 802.3at (PoE+), IEEE 802.3bt (4PPoE)
Max. conductor resistance at 20°C	160 Ω/km
Possible data transmission rates	10000
Test voltage	0.7 kV
Signal propagation speed (nom.)	0.79
Test voltage core/screening	0.7
Test voltage core/core	0.7
Conductor/conductor operating capacitance (800Hz), approx.	45

Product Design

Nominal core diameter	1.33
Conductor design	solid conductor
Nominal outer diameter	7.3 mm
Conductor material	Bare copper
Min. outer diameter	7.0
Conductor count/size	4x2x23/1AWG
Shielded
Core identification	Colours
Shape of cable	Round
Number of pairs	4
Outer sheath colour	ivory
Stranding type	Twisted-pair
Pair screening type	Aluminium-laminated plastic foil
Leading conductor cross-section	AWG
Abbreviation shielding	S/FTP
Cable sheath RAL colour	RAL 1015
With rodent protection
Type of overall screen	Tin-plated copper braiding
Number of cores	8
Nominal conductor cross-section (AWG)	23 AWG
Core insulation basic material	Polyethylene foam
Basic material of outer sheath	Polyamide
Including protective earth
Core insulation basic material, short form	Foam-Skin PE
With armouring
Max. outer diameter	7.6
Number of wires	1
Basic material of outer sheath, short form	PVC

Product Characteristics

Flame-retardant
PWIS-free according to	VDMA 24364-B2-L
Fast Connect (FC) cable
Installation temperature min.	0
UV-resistant
Minimum bending radius in mm, fixed installation	30.4 mm
PWIS-free
Application area	Fixed installation
Oil-resistant
Ethernet cable category	Cat.6A
Minimum bending radius in mm, occasionally flexing	60.8 mm
Max. assembly temperature	50
Minimum bending radius, stationary	4 x outer diameter
Minimum bending radius, occasionally flexing	8 x outer diameter
Flame retardance according to	IEC 60332-1-2
Windable
Halogenfree

Certifications and Standards

Documentation

Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Product Family List

Article number	Conductor count/size	Abbreviation shielding	Nominal outer diameter	Halogenfree	Weight
2170143	4x2x23/1AWG	S/FTP	7.3	No	58 kg/km
2170960	4x2x23/1AWG	S/FTP	7.3	No	58 kg/km
2170961	4x2x23/1AWG	F/UTP	7.4	No	60 kg/km
2170962	4x2x23/1AWG	F/FTP	7.3	Yes	60 kg/km
2170963	4x2x23/1AWG	F/UTP	7.4	Yes	60 kg/km
